Lubrication Equipments

Showing all 4 results

Pneumatic Piston Grease Pump, Pumpmaster 35, Pm35 – 60:1, 185 Kg (400 Lb) Drums, Npt

Maximum free flow delivery (SI)	2 kg/min, 4.4 lb/min, 2 kg/min
Air motor effective diameter	80 mm (3.15 “)
Delivery per cycle	900 g/min (2 lb)
Maximum outlet pressure	600 bar (8700 psi)
Total height	1212 mm (47.7 “)
Air consumption	450 NL/min (15.9 scfm)
Air pressure operating range	2 – 10 bar (29 – 145 psi)
Air inlet	3/8″ NPT (F)
Fluids	Grease
Wetted materials	Viton, PTFE, Hard chromed steel, NBR, Cast iron, Steel, UHMWPE
Cycles per litre (aprox.)	80 cycles
Pump mounting	185 kg (400 lb) drums
Fluid outlet	3/8″ NPT (F)
Fluid inlet type	Chop-check
Noise level	80 dB
Weight	11 kg (24.2 lb)
Fluid inlet	–
Pressure ratio	60:1
Delivery	900 g/min (2 lb/min)
Air motor stroke	80 mm (3.15 “)
Tube height	925 mm (36.4 “)

Total height	469 mm (18.5 “)
Air pressure operating range	2 – 12 bar (29 – 174 psi)
Delivery per cycle	12 l (3.2 gal)
Wetted materials	Hard chromed steel, Steel, Polyurethane, NBR, Aluminium
Air motor stroke	80 mm (3.15 “)
Air motor effective diameter	80 mm (3.15 “)
Fluid inlet	1 1/2″ NPT (F)
Maximum free flow delivery (SI)	30 l/min, 8 gal/min, 30 l/min
Air consumption	350 NL/min (12.4 scfm)
Fluid inlet type	Ball check
Fluids	Hydraulic oil, Gear oil, Lubricant oil, Transmission fluid
Pump mounting	Universal stub pump
Cycles per litre (aprox.)	80 cycles
Weight	5.3 kg (11.7 lb)
Fluid outlet	1/2″ NPT (F)
Delivery	12 l/min (3.2 gal/min)
Noise level	80 dB
Maximum outlet pressure	60 bar (870 psi)
Tube height	200 mm (7.9 “)
Air inlet	3/8″ NPT (F)
Pressure ratio	5:1

Fluids	Corrosion protection fluids, Lubricant oil, Hydraulic oil, Gear oil, Transmission fluid
Noise level	80 dB
Fluid inlet type	Ball check
Air inlet	3/8″ NPT (F)
Pressure ratio	8:1
Air pressure operating range	2 – 12 bar (29 – 174 psi)
Maximum free flow delivery (SI)	17 l/min, 4.5 gal/min, 17 l/min
Cycles per litre (aprox.)	80 cycles
Air motor stroke	80 mm (3.15 “)
Air motor effective diameter	80 mm (3.15 “)
Delivery	7 l/min (1.9 gal/min)
Pump mounting	Universal stub pump with bung adaptor
Maximum outlet pressure	96 bar (1392 psi)
Fluid inlet	1″ NPT (F)
Wetted materials	Hard chromed steel, NBR, Polyurethane, Cast iron, Steel
Fluid outlet	1/2″ NPT (F)
Total height	487 mm (19 “)
Delivery per cycle	7 l (1.9 gal)
Weight	6.8 kg (15 lb)
Air consumption	350 NL/min (12.4 scfm)
Tube height	200 mm (7.9 “)

Air motor stroke	100 mm (4 “)
Fluids	Hydraulic oil, Lubricant oil, Transmission fluid, Gear oil
Air consumption	1100 NL/min (38.8 scfm)
Weight	19 kg (42 lb)
Cycles per litre (aprox.)	60 cycles
Noise level	80 dB
Maximum free flow delivery (SI)	100 l/min, 100 l/min, 26.4 gal/min
Wetted materials	NBR, Polyurethane, Nickel, Cast iron, Aluminium, Steel
Delivery per cycle	35 l (9.25 gal)
Fluid outlet	3/4″ NPT (F)
Maximum outlet pressure	72 bar (1044 psi)
Pressure ratio	6:1
Delivery	35 l/min (9.2 gal/min)
Fluid inlet type	Ball check
Air pressure operating range	1.5 – 12 bar (21.75 – 174 psi)
Air inlet	1/2″ NPT (F)
Air motor effective diameter	150 mm (6 “)
Total height	716 mm (28.2 “)
Pump mounting	Universal stub pump
Tube height	200 mm (7.9 “)
Fluid inlet	1 1/2″ NPT (F)
